Woven Gabion Wall HDG Mesh For Hydraulic Riverbank Retaining Wall Construction

Brand Name : KN

Model Number : KN-gabion wall

Certification : CE ISO SGS COC PVOC

Place of Origin : CN

MOQ : 100 pc

Price : USD 35-50

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 pc per day

Delivery Time : 15 work days

Packaging Details : pallet

Product Name : Woven Gabion HDG Mesh For Hydraulic Riverbank Retaining Wall Construction

Key Words : Gabion wall

Tensile Strength : 350-500N/mm²

Color : green,black,

Mesh Type : Hexagonal

Size : 2m x 1m x 1m

Payment : T/T or L/C

Mesh Hole : 6*8cm,8*10cm...

Type : Hexagonal wire mesh, Double Twist

Wire Diameter : 2.0-4.0mm

Contact Now

Woven Gabion HDG Mesh for Hydraulic Riverbank Retaining Wall Construction

Woven Gabion Wall, formed with double-twisted hexagonal steel wire (Hot-Dip Galvanized/Galfan-coated), is utilized in hydraulic engineering for constructing weir foundations, harbor breakwaters, and drainage channel reinforcement. Its flexible mesh structure supports rock or concrete fill to dissipate hydraulic energy in tidal barrier systems, storm surge protection, and irrigation canal embankments. Compliant with EN 10223-3 specifications, modular units (1.5x1x0.5m to 3x2x1m) enable rapid deployment in sediment control basins, culvert headwalls, and river delta stabilization projects under dynamic aquatic conditions.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Customization Services

Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

gabion specifications			Mesh hole modle
			8x10cm		6x8cm
Length(m)	Width(m)	Height(m)	Galvanized or PVC coated		Galvanized or PVC coated
			Mesh diameter	Zinc	Mesh diameter	Zinc
2	1	1	2.7mm	>245g/m²	2.0mm	>215g/m²
3	1	1	Side wire diameter	Zinc	Side wire diameter	Zinc
4	1	1	3.4mm	>265g/²	2.7mm	>245g/m²
6	1	1	Binding wire diameter of 2.7m		Binding wire diameter of 2.0m
